GEOMETRY ISSUES
Geometry in CRT (Cathode Ray Tube) technology refers to the overall shape and alignment of the displayed image on the screen. It is essential to ensure that the image appears proportionate, with straight lines and correct proportions, without any distortion or misalignment.
Achieving proper geometry in a CRT display involves several factors:
Horizontal Linearity: Horizontal linearity refers to the consistency of the width of the displayed image from left to right. If the image appears stretched or compressed horizontally, it indicates a horizontal linearity issue.
Vertical Linearity: Vertical linearity pertains to the consistency of the height of the displayed image from top to bottom. If the image appears stretched or compressed vertically, it indicates a vertical linearity issue.
Pincushion Distortion: Pincushion distortion causes the image to appear curved inward or outward, resembling a pincushion shape. It can occur due to magnetic fields, improper voltage regulation, or component aging.
Barrel Distortion: Barrel distortion causes the image to appear curved outward, resembling the shape of a barrel. It can also result from magnetic fields or improper voltage regulation.
Trapezoidal Distortion: Trapezoidal distortion causes the sides of the image to slant inward or outward, resulting in a trapezoid-like shape. It can occur if the horizontal or vertical scanning circuits are misaligned.
Achieving optimal geometry requires careful adjustment of the CRT's electronic components and magnetic fields. CRT monitors often include built-in controls, such as horizontal and vertical size, position, and linearity adjustments, to correct geometry issues.
Regular calibration and adjustment are necessary to maintain proper geometry in CRT displays. Professional calibration tools and expertise may be required to achieve precise alignment.
It's important to note that geometry issues in CRT displays can worsen over time due to component aging and magnetic interference. Regular maintenance and periodic adjustments can help ensure accurate and visually pleasing geometry for optimal viewing experiences.
